United Brothers Metal Products Co., Ltd. is one of the leading manufacturers and suppliers of 2pc flanged ball valve(ansi) in Vietnam, also supports customized service. If you're going to buy bulk advanced 2pc flanged ball valve(ansi), welcome to get free sample from our factory. Quality products and low price are available.
Product Introduction
Built for durability and precision, 2PC Flanged Ball Valve (ANSI) from United Brothers ensures positive shut-off and smooth flow control under demanding conditions. Featuring investment cast construction and a blow-out proof stem, it complies with ASME B16.34 and API598 standards. Certified under PED97/23/EC (CE 0035) and AD2000-W0, the valve operates reliably across temperatures from -20°C to 180°C, making it a trusted choice for critical fluid handling applications.
Product Specifications
|
Feature |
Specification |
|
Size Range |
1/2″ to 6″ |
|
Pressure Rating |
Class 150 |
|
Temperature Range |
-20°C to 180°C |
|
Port Type |
Full Port |
|
Casting Method |
Investment Casting |
|
Stem Design |
Blow-out Proof |
|
Mounting |
ISO 5211 Mounting Pad |
|
Pressure Equipment Directive |
PED 97/23/EC (CE 0035) Approved |
|
Casting Approval |
AD2000-W0 |
|
Design Standard |
ASME B16.34 |
|
End Flange Standard |
ASME B16.5 |
|
Inspection & Testing Standard |
API598 |
|
Brand |
United Brothers |
Manufacturing Process
|
Step |
Process |
|
01 |
CAD Drawing, 3D Modeling |
|
02 |
Materials |
|
03 |
Wax Pattern Injection |
|
04 |
Ceramic Shell Building |
|
05 |
Dewaxing & Shell Firing |
|
06 |
Melting & Investment Casting (Pouring) |
|
07 |
Cut-off & Sandblasting |
|
08 |
Heat Treatment |
|
09 |
Rough Machining |
|
10 |
Fine Machining |
|
11 |
Hydrostatic / On-Site Inspection |
|
12 |
General Inspection |
|
13 |
Painting |
|
14 |
Packaging / Shipping |
Applications
The United Brothers 2PC Flanged Ball Valve (ANSI) is specified across a wide spectrum of industries. In chemical and petrochemical facilities, it handles corrosive and aggressive fluids with minimal maintenance. In oil and gas applications, it provides secure isolation and dependable flow control under variable pressures. The valve's clean design and material compatibility also make it a strong fit for water treatment plants, food and beverage processing lines, and pharmaceutical production - where hygiene, precision, and repeatability are non-negotiable. Beyond these, the valve is regularly deployed in shipbuilding, mining operations, pulp and paper mills, sugar refineries, and HVACR systems.
